Product Usage

Stainless Steel 420 Sheets and Plates are used in a wide range of applications and various industries. Below are a few of them:Petrochemical Industry,Oil and Gas Industry,Chemical Industry,Power Plant Industry,Energy Industry,Pharmaceuticals Industry,Pulp & Paper Indusry,Food Processing Industry,Aerospace Industry,Refining Industry,etc

Product Specifications

Commodity	Austenitic, Ferritic, Martensitic, Duplex, Cold rolled, Hot rolled
Grade	201, 202, 301, 304, 304j1, 304l, 321, 309s, 310s, 2205, 409l, 410, 410s, 420, 420j1, 420j2, 430, 439, 409l, 443, 444, etc
Standard	ISO, JIS, ASTM, AS, EN, GB
Surface	N0.1, N0.2, N0.3, N0.4, N0.5, N0.6, N0.7, N0.8, 2D, 2B, HL, BA, 6K, 8K, etc
Thickness	0.1-200mm
Width	10-2000mm
MOQ	1MT
Packaging	Export standard, seaworthy
Trade Term	FOB, CFR, CIF
Transport Type	Container, bulk and train
Loading port	qingdao, tianjin, etc
Payment terms	T/T, L/C at sight,West Union,D/P,D/A,Paypal
Delivery time	15-35 days after confirmed order

Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Ni
420	0.15 max	1.00 max	1.00 max	0.04 max	0.03 max	min: 12.0 max: 14.0	-

Mechanical Behavior

Tempering Temperature (°C)	Tensile Strength (MPa)	Yield Strength 0.2% Proof (MPa)	Elongation (% in 50mm)	Hardness Brinell (HB)
Annealed *	655	345	25	241 max
399°F (204°C)	1600	1360	12	444
600°F (316°C)	1580	1365	14	444
800°F (427°C)	1620	1420	10	461
1000°F (538°C)	1305	1095	15	375
1099°F (593°C)	1035	810	18	302
1202°F (650°C)	895	680	20	262
* Annealed tensile properties are typical for Condition A of ASTM A276; annealed hardness is the specified maximum.
