Product Application

304 stainless steel strip is the most widely used chromium-nickel stainless steel strip.

It has good corrosion resistance, heat resistance, low temperature strength and mechanical properties.

This strip has good hot workability such as stamping and bending without heat treatment. It is resistant to corrosion in the atmosphere.

It is suitable for food processing line, storage and transportation, plate heat exchangers, bellows, household products, auto parts, medical appliances, building materials, chemicals industry, food industry, agriculture, ship parts, etc.

304 stainless steel is a nationally recognized food grade stainless steel material.

Product Details

Name	Stainless steel strip
Material	mainly201, 304, 316, 316L, 410, 430, etc 300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347 200series:201,202,202cu,204 400series:409,409L,410,420,430,431,439,440,441,444 Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304 Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
Standard	JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc
Finish	NO.1,1D
Thickness	3.0-6.0mm
Width	2 - 2000mm
Length	50mm-2000m/2438/3048mm as customer' s requirement
Size	4mm10mm1219mm, 5mm10mm1219,6mm10mm1219, or as required
Color	Golden, Black , Sapphire Blue, Brown, Rose gold, Bronze, Purple, gray, silver, Champagne, violet, blue diamond, etc
Application	automobile ,aviation,machinery,construction,automobile, roof,electrician
Lead time	7 to 25 working days after the receipt of 30% deposit
Payment terms	30%TT for deposit, 70% balance before shipment or LC at sight
Packing	Wooden pallet or according to customer's request

Chemical Composition

	C	Mn	Si	P	S	Cr	Ni	N
304	0.07max	2.0max	0.75max	0.045max	0.03max	min: 18.0 max: 20.0	min: 8.0 max: 10.5	-

	Cr	Ni	Mo	Mn	Si	P	S	C	Fe
316	16%-18%	10%-14%	2%-3%	2%	0.75%	0.045%	0.03%	0.08%	margin

	C	Si	Mn	S	P	Cr	Ni	Mo
316L	≤0.030	≤1.00	≤1.00	≤0.030	≤0.045	16.00～18.00	10.00～14.00	2.00～3.00

Mechanical behavior

Grade	Tensile Strength ksi (min)	Yield Strength 0.2% ksi (min)	Elongation %	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
304	75	30	40	201	92

Grade	Yield Strength（Mpa）	Tensile intensity（Mpa）	Elongation（%）	Hardness（HBW）
316	≥205	≥515	≥35	≤217

Grade	Tensile intensity（Mpa）	Yield Strength σ0.2（Mpa）	Elongation δ5（%）	Hardness（HB)	Rate of reduction in area ψ（%）
316L	≥480	≥177	≥40	≤187	≥60
