Properties & Typical Applications

409L is known to reduce the width of the consume system.It is available at a low cost but offers good flexibility and offers good corrosion resistance against gas corrosion.It can be used in high efficiency engines, exhaust systems, thermal switches, slurry wheels, etc., as well as in automobile frames and heat exchangers.

Product Description

409L Stainless Steel Strip Specification

Product Name	Stainless Steel Strips
Length	As required
Width	3mm-1219mm or as required
Thickness	0.1mm-6.0mm or as required
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique	Hot rolled / cold rolled
Surface Treatment	2B or according to customer requirement
Thickness tolerance	±0.01mm
Material	201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 409L ,410, 410S,420, 430, 431, 440A,904L
Application	It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen.
Application
Shipment time	Within 15-20 workdays after receiving deposit or L/C
Export packing	Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Export packing
Capacity	250,000 tons/year

Chemical Composition

Grade	Standard	409L Chemical Composition
		C	Si	Mn	Cr	Ni	P	S	Mo	Others
		≤ %	≤ %	%	%	%	≤ %	≤ %	≤ %	%
409L	ASTM A240	0.03	1.0	2.0	10.5 - 12.5	0.6	0.04	0.015	-	Ti≤ 0.65
1.4512	EN 10088-2	0.03	1.0	1.0	10.5 - 11.5	0.6	0.04	0.03	-	Ti≤ 0.65

Mechanical Properties

Grade	Standard	409L Mechanical Properties
		Tensile Strength	Yield Strength 0.2%	Elongation >%	Hardness
		(MPa) ≥	(MPa) ≥	Elongation >%	HRB ≤	HB ≤
409L	ASTM A240	380	210	25	-	175
1.4512	EN 10088-2	360	175	25	-	-
