Product Usage

410S stainless steel pipe is often used in:Petroleum Refining and Petrochemical Processing,Ore Processing,Thermal Processing,Gate valves,Press plates,etc

Product Specification,

Product Name	Stainless steel pipe
Standard	ASTM AISI DIN, EN, GB, JIS
Steel Grade	200 Series: 201,202 300 Series: 301,304,304L,316,316L,316Ti,317L,321,309s,310s 400 Series: 409L,410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L,2205,2507,2101,2520,2304
Outer Diameter	6-2500mm(as required)
Thickness	0.3mm-150mm (as required)
Length	2000mm/2500mm/3000mm/6000mm/12000mm(as required)
Technique	Seamless/Welded
Surface	No.1 2B BA 6K 8K Mirror No.4 HL
Tolerance	±1%
Price Terms	FOB,CFR,CIF

Chemical Composition

Chromium	11.5 min.-14.5 max.	Sulfer	.030 max.
Nickel	0.60 max.	Silicon	1.00 max.
Carbon	0.08 max.	Iron	Balance*
Manganese	1.00 max.	Phosphorus	0.040 max.

Mechanical Behavior

Yield Strength 0.2% Offset		Ultimate Tensile Strength		Elongation in 2 in.%	Hardness Rockwell B	Reduction percent of area
psi	(MPa)	psi	(MPa)	Elongation in 2 in.%	Hardness Rockwell B	Reduction percent of area
42,000	290	64,400	444	33	75	65
