Common uses of Stainless Steel Pipe 316 include:Boat Fittings,Brewery Equipment,Chemical Transportation Containers,Chemical & Petrochemical Equipment,Coastal Architectural Paneling,Coastal Balustrading,Food Processing Equipment,Heat Exchangers,Medical Implants,Mining Screens,Nuts & Bolts,Laboratory Benches & Equipment,Springs,etc
Model | Stainless steel pipe | |||
Standard | ASTM A213, ASTM A312, ASTM A789, ASTM A790 | |||
Material Grade | 201/202/304/316/S31803/S32750 | |||
Outer Diameter | 0.1mm-219.1mm | |||
Thickness | 0.05mm-20mm | |||
Length | ≤12000mm or as per customer request | |||
| a) Outer Diameter: +/-0.2mmb) Thickness: +/- 10% OR as customer request | |||
| Satin / Hairline: 180#, 320#Polish: 400#, 600#, 800# or Mirro surface | |||
Application | Decoration (Processed into raillings, handrails, doors and Windows),medical, industry, etc | |||
packing | Plastic bag/woven packing(please send details packing to us if you have other requirements) | |||
| Grade | 316 | |
|---|---|---|
| min | max | |
| C | – | 0.08 |
| Mn | – | 2.0 |
| Si | – | 0.75 |
| P | – | 0.045 |
| S | – | 0.03 |
| Cr | 16.0 | 18.0 |
| Mo | 2.0 | 3.0 |
| Ni | 10.0 | 14.0 |
| N | – | 0.10 |
| Grade | 316 | |
|---|---|---|
| Tensile Strength (MPa) min | 515 | |
| Yield Strength 0.2% Proof (MPa) min | 205 | |
| Elongation (% in 50mm) min | 40 | |
| Hardness | Rockwell B (HR B) max | 95 |
| Rockwell B (HR B) max | 217 | |
