321 stainless steel is an austenitic stainless steel alloy that contains 17% chromium, 9% nickel, and 2% molybdenum. It also has titanium added to the mix, increasing its strength and stability further. This combination of elements results in an alloy with excellent resistance to intergranular corrosion after exposure to temperatures in the chromium-carbide precipitation range from 800 to 1500°F (427 to 816°C). In addition, this alloy has excellent toughness even down to cryogenic temperatures.
1.321 stainless steel is a chromium-nickel stainless steel that offers many advantages over other types of stainless steel.
2.The addition of titanium to 321 stainless steel makes it an ideal choice for applications where high temperatures are a concern.
3.321 stainless steel is resistant to intergranular corrosion, making it an ideal choice for welding applications.
4.321 stainless steel offers excellent resistance to stress corrosion cracking, making it an ideal choice for chemical processing applications.
5.321 stainless steel is non-magnetic, making it an ideal choice for food preparation and medical applications.
Specification
| Product Name | 321 Stainless Steel Pipe/Tube |
| Type | Seamless and welding pipe/tube |
| Shape | Round pipe, Square pipe, Rectangular pipe |
| Material | 200/300/400/900 series,duplex |
| 201, 202, 203, 204, 301, 304, 304L, 314, 316, 316L, 310S 309S, 409, 410, 420, 430, 631, 904L,etc | |
| Standard | JIS/SUS/GB/DIN/ASTM/AISI/En |
| Surface | Pickling/Polished/Satin/Hairline/Mirror Finish |
| Package | clients' requirement and Standard export sea-worthy packing |
| MOQ | 1 ton |
| Dimension | Range |
| Outside Diameter | 6mm-630mm(seamless pipe) 9.5mm-1200mm(welding pipe) or as customer's requirement |
| Wall Thickness | 2.5mm-30mm(seamless pipe) 20.5mm-20mm(welding pipe) or as customer's requirement |
| Length | 6M & as customer's requirement |
Chemical composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Other | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 321 | min. max | – 0.08 | 2.00 | 0.75 | 0.045 | 0.030 | 17.0 19.0 | – | 9.0 12.0 | 0.10 | Ti=5(C+N) 0.70 |
Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50 mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 321 | 515 | 205 | 40 | 95 | 217 |
