Stainless steel pipe introduction

1. The heater is generally used in the oil refining unit; 2. Chemical plant equipment pipeline; 3. Fast cooling cylinder for solid solution used in textile industry; 4. Seamless steel pipe for heat exchanger and condenser. 5. High pressure seamless steel pipe for food (gb-2000) is a high-quality carbon structural steel and alloy steel seamless steel pipe suitable for chemical equipment and pipes with working temperature of - 40~400 ° C and working pressure of 10~30ma. 6. Seamless steel pipes for geological drilling and oil drilling control. 7. Cracking pipe for petrochemical industry is used to transport high-temperature and high-pressure fluid on fertilizer equipment.

Stainless steel pipe details

Stainless steel pipe specification

Stainless steel pipe
Standard	Food Grade Sanitary Tube: JIS G3447, KS D 3585, ASTM A270, EN 10357(DIN 11850), AS 1528.1, ISO 2037(NF A49-249)
	Heat exchanger tube: ASTM A249 / ASME SA249, GB / T 24593-2009, HG 20537.2
	Industrial pipe: ASTM A312, EN 10217-7, GB / T 12771-2008, HG 20537.3
	Drinking water tube: GB / T 19228
	Mechanical tube: ASTM A554, EN 10296-2
Size	Outer Diameter Range: 9.5~2000mm Thickness Range: 0.5~20mm (Size can be customized.) Length: Up to 18.3 meters per piece.
Shape Section	Round, square, rectangular
Usage	Sanitary tubing: for food processing industry, beverage industry, sugar mill and so on; Heat exchanger tube: condenser, boiler, super heater, evaporator and so on; Industiral pipe: for petroleum delivery, gas delivery, petrochemical industry, wastewater treatment, drainage system, and so on; Mechanical tube: handrail, railings, balustrade, hence and so on.

Stainless steel pipe Chemical composition

GRADE
GRADE	CHEMICAL COMPOSITION (% BY MASS - MAX UNLESS STATED)
-	C	Si	Mn	S	Cr	Ni	Mo	P	N
1.4301	0.07	1.0	2.0	0.03	17.0/19.5	8.0/10.5	-	0.045	0.11
1.4436	0.05	1.0	2.0	0.015	16.5/18.5	10.5/13.0	2.5/3.0	0.045	0.11
1.4429	0.03	1.0	2.0	0.015	16.5/18.5	11.0/14.0	2.5/3.0	0.045	0.12/0.22
1.4162	0.04	1.0	4.0/6.0	0.015	21.0/22.0	1.35/1.75	0.1/0.8	0.040	0.20/0.25
1.4362	0.03	1.0	2.0	0.015	22.0/24.0	3.5/5.5	0.1/0.6	0.035	0.05/0.20
1.4462	0.03	1.0	2.0	0.015	21.0/23.0	4.5/6.5	2.5/3.5	0.035	0.10/0.22
1.4501	0.03	1.0	1.0	0.015	24.0/26.0	6.0/8.0	3.0/4.0	0.035	0.20/0.30
1.4529	0.02	0.50	1.0	0.010	19.0/21/0	24.0/26.0	6.0/7.0	0.030	0.15/0.25

Stainless steel pipe Mechanical property

GRADE
GRADE	TENSILE PROPERTIES (MIN UNLESS STATED)
-	0.2% Proof strength, Rp0.2	Stress Ratio, Rm/Rp0.2	Elongation at fracture, A5	Total elongation at maximum force, Agt

200	200	1.10	22	5
500	500	1.10	14	5
650	650	1.10	14	5

Stainless steel pipe features

1.Our stainless steel tubes pipes are treated by bright annealing, inside weld bead removing, precise polishing. The roughness of tubes could be under 0.3μm.

2.We have the non destructive testing ( NDT ), eg. online eddy current inspection and hydraulic or airtightness testing.

3. Thick welding, good appearance.The mechanical properties of tube could be tested.

4. The raw material is from Taigang, Baogang, Zhangpu and so on.

5. And Our tubes are certificated by AD 2000-W0, PED 2014/68/EU, ISO 9001 : 2015.

6. Full material traceability is guaranteed during the manufacturing process.

7. Polished tube is supplied in individual plastic sleeves with capped ends ensuring optimum cleanliness.

8. Internal Bore: Tubes have a smooth, clean and crevice free bore.
