Product Usage

420 stainless steel coil is often used in Shear blades,Needle valves,Surgical equipment,Cutlery,Heat Treatment baskets and jigs,Architectural applications,Gas turbines,Expansion joints,Spiral Welded tube for burner pipes and flues,Welding filler wire and electrodes,Heat Exchangers,etc

Product Specifications

Item	420 Stainless Steel Coil
Standard	ASTM A240, JIS4304-2005, ASTM A167, EN10088-2-2005, GB/T3280-2007, etc
Material	Stainless Steel 420 Coil
Surface	the surface and finish of 420 Stainless Steel Coil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Thickness	0.3mm~200mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Package	Standard export package, suit for all kinds of transport, or as required.

Chemical Composition

Grade

420

min.

max.

0.15

0.040

0.03

12.0

14.0

Mechanical Behavior

Tempering Temperature (°C)	Tensile Strength (MPa)	Yield Strength 0.2% Proof (MPa)	Elongation (% in 50mm)	Hardness Brinell (HB)	Impact Charpy V (J)
Annealed *	655	345	25	241 max	-
204	1600	1360	12	444	20
316	1580	1365	14	444	19
427	1620	1420	10	461	#
538	1305	1095	15	375	#
593	1035	810	18	302	22
650	895	680	20	262	42
* Annealed tensile properties are typical for Condition A of ASTM A276; annealed hardness is the specified maximum. # Tempering of this steel should be avoided in the range 425-600°C
