Stainless Steel Coil

line

China manufacturer 309 stainless steel coil

Product Usage

309 stainless steel coil is often used in Automotive,Railway & Transport,Architecture, Building & Construction,Chemical & Petrochemical Industries,Pharmaceutical,Energy and Power,Oil and Gas Industries,Kitchenware and Food Processing Industries,Plumbing And Overhead Water Tanks,etc

Product Specifications

Product Name

Stainless Steel Coil

Length

as required

Width

3mm-2500mm or as required

Thickness

0.03mm-300mm or as required

Standard

AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc

Technique

Hot rolled / cold rolled

Surface Treatment

No.1,2B,BA,No.4,HL,Mirror or according to customer requirement

Thickness Tolerance

±0.01mm

Material

201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L

Application

It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture,
ship components.
It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs,
and screen.

MOQ

1 ton , We can accept sample order.

Shipment Time

Within 3-5 workdays after receiving deposit or L/C

Export Packing

Waterproof paper, and steel strip packed.
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required

Capacity

250,000 tons/year

Chemical Composition

Element309
Chromium22.0 min.-24.0 max.
Nickel12.0 min.-15.0 max.
Carbon0.20
Manganese2.00
Phosphorus0.045
Sulfer0.030
Silicon0.75
IronBalance

Mechanical Behavior

PropertiesMetricImperial
Tensile strength, ultimate620 MPa89900 psi
Tensile strength, yield (0.2%)310 MPa45000 psi
Izod impact120 - 165 J88.5 - 122 ft-lb
Modulus of elasticity200 GPa29000 ksi
Shear modulus77 GPa11200 ksi
Poissons ratio0.30.3
Elongation at break (in 50 mm)45%45%
Hardness, Brinell (converted from Rockwell B hardness)147147
Hardness, Knoop (converted from Rockwell B hardness)164164
Hardness, Rockwell B8585
Hardness, Vickers (converted from Rockwell B hardness)169169
