Stainless Steel Coil

line

Cold rolled 309 stainless steel coil

Product Usage

319 stainless steel coil is often used in Automotive,Railway & Transport,Architecture, Building & Construction,Chemical & Petrochemical Industries,Pharmaceutical,Energy and Power,Oil and Gas Industries,Kitchenware and Food Processing Industries,Plumbing And Overhead Water Tanks,etc

Product Specifications

Product Name

Stainless Steel Coil

Standard

AISI, ASTM, BS, DIN, EN, GB, JIS

Grade

201 301L, 301, 310S, 410, 316L, 316, 314, 430, 304, 304L, 305

Thickness

0.025-4mm

Width

3.5mm-1550mm

Tolerance

+/-0.02mm

Surface treatment

BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D

Coil ID

508/610mm

Coil Weight

2-5 tons

Technique

Cold rolled

Package

Standard seaworthy export packing:

3 layers of packing, inside is kraft paper, water plastic film is in the middle and outside
GI steel sheet to be covered by steel strips with lock, with inner coil sleeve

Certification

ISO 9001-2008, SGS, CE, BV

MOQ

25 Tons

Delivery

15-20 days

Monthly Output

30000 Tons

Payment

T/T, L/C, Western Union, Paypal

Remarks

Insurance is all risks and accept the third party test

Chemical Composition

Element309
Chromium22.0 min.-24.0 max.
Nickel12.0 min.-15.0 max.
Carbon0.20
Manganese2.00
Phosphorus0.045
Sulfer0.030
Silicon0.75
IronBalance

Mechanical Behavior

PropertiesMetricImperial
Tensile strength, ultimate620 MPa89900 psi
Tensile strength, yield (0.2%)310 MPa45000 psi
Izod impact120 - 165 J88.5 - 122 ft-lb
Modulus of elasticity200 GPa29000 ksi
Shear modulus77 GPa11200 ksi
Poissons ratio0.30.3
Elongation at break (in 50 mm)45%45%
Hardness, Brinell (converted from Rockwell B hardness)147147
Hardness, Knoop (converted from Rockwell B hardness)164164
Hardness, Rockwell B8585
Hardness, Vickers (converted from Rockwell B hardness)169169
