409l stainless steel coils are often used in automotive exhaust systems: exhaust manifolds, catalytic converters, mufflers, etc.
Commodity | Austenitic, Ferritic, Martensitic, Duplex, Cold rolled, Hot rolled |
Grade | 201, 202, 301, 304, 304j1, 304l, 321, 309s, 310s, 2205, 409l, 410, 410s, 420, 420j1, 420j2, 430, 439, 409l, 443, 444, etc |
Standard | ISO, JIS, ASTM, AS, EN, GB |
Surface | N0.1, N0.2, N0.3, N0.4, N0.5, N0.6, N0.7, N0.8, 2D, 2B, HL, BA, 6K, 8K, etc |
Thickness | 0.1-200mm |
Width | 10-2000mm |
MOQ | 1MT |
Packaging | Export standard, seaworthy |
Trade Term | FOB, CFR, CIF |
Transport Type | Container, bulk and train |
Loading port | qingdao, tianjin, etc |
Payment terms | T/T, L/C at sight,West Union,D/P,D/A,Paypal |
Delivery time | 15-35 days after confirmed order |
| Grade | C | Ni | Si | S | Mn | P | Cr | Ti | |
| SS 409L | min. | – | – | – | – | – | – | 10.5 | 6(C+N) |
| max. | 0.03 | 0.5 | 1.00 | 0.02 | 1.00 | 0.04 | 11.75 | 0.75 | |
| Gr 409L | Tensile Test | Hardness Test | Bend Test | ||||
| 0.2%Y.S. | 1%Y.S. | T.S. | EL (%) | HRBW | HV | 180° | |
| Min | 170 | — | 380 | 20 | — | — | 0.5t |
| Max | N/mm2 | — | N/mm2 | — | 88 | ||
