Alloy 317 is commonly used to handle sulfur, pulp liquor, acid dyestuffs, acetylating and nitrating mixtures, bleaching solutions, severe coal and oil, and many chemical compounds. Some other applications that use alloy 317 include:Paper and pulp handling equipment,Chemical and petrochemical processing equipment,Condensers in fossil and nuclear fueled power generation stations,Food processing equipment,Textile equipment,etc
Item |
|
Standard | ASTM A479,ASTM A276,ASTM A484, ASTM A582, |
Item | Stainless steel bar/rod |
Standard | ASTM A479,ASTM A276,ASTM A484, ASTM A582, |
Material | 301, 304, 304L, 309S, 321, 316, 316L, 317, 317L, 310S, 201,202 |
Specifications | Round bar:Diameter 0.1~500mmAngle bar:Size 0.5mm*4mm*4mm~20mm*400mm*400mm |
Length | 2m, 5.8m, 6m, or as required. |
Surface | Black, peeled, polishing, bright, sand blast, hair line, etc. |
Price Term | Ex-work, FOB, CFR, CIF, etc. |
Payment Term | A: 100% T/T advance. ( For small order<$5000.)B: 30% T/T and balance before shipping .C: 30% T/T advance, balance L/C at sight D: |
Package | Export standard package, bundled or be required. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
