420 stainless steel bar

We supply the highest quality steel

[email protected]

13370586666

Stainless Steel Bar

Home > product > Stainless steel > Stainless Steel Bar

Page Navigation

Product Usage Product Specification Chemical Composition Mechanical Behavior Factory Other types Customer Factory Inspection

Quote Online

Product Usage

Alloy 420 is used for a variety of applications where good corrosion and outstanding hardness is necessary. It is not usually used at temperatures exceeding 800^oF (427^oC) due to quick hardening and loss of corrosion resistance. Examples of applications that use alloy 420 include:Cuttery,Knife blades,Surgical instruments,Needle valves,Shear blades,Scissors,Hand tools,etc.

Product Specification

Stainless Steel Bar
Standard	AiSi ASTM bs DIN GB JIS EN
Steel Grade	200 series: 201, 202
	300 series: 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S,309S,2205,2507,2520
	400 series: 410, 410S,420, 430, 431, 440A,904L
	Duplex stainless steel series:SAF2304,S31500,S31803,S32900,S31260,S32750,S32550
Place of Origin	China
Place of Origin	Zhejiang
Application	chemical industry, shipping industry, manufacturing industry, construction,decorate Industry,electric power, pump shafts,sanitary wares,furniture handles,boiler,high temperature resistant,low temperatureresistant,corrosion resistant etc.
Diameter	3-800mm or as required
Length	1-12m as required
Shape	Round
Special Use	Valve Steels
Tolerance	±1%
Processing Service	Bending, Welding, Decoiling, Cutting
Surface Finish	2B
Delivery Time	8-14 days
SEAWORTHY PACKING	20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM
	40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM
	40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM

Chemical Composition

	C	Mn	Si	P	S	Cr
420	0.15 max	1.00 max	1.00 max	0.04 max	0.03 max	min: 12.0 max: 14.0

Mechanical Behavior

empering Temperature (°C)	Tensile Strength (MPa)	Yield Strength 0.2% Proof (MPa)	Elongation (% in 50mm)	Hardness Brinell (HB)
Annealed *	655	345	25	241 max
399°F (204°C)	1600	1360	12	444
600°F (316°C)	1580	1365	14	444
800°F (427°C)	1620	1420	10	461
1000°F (538°C)	1305	1095	15	375
1099°F (593°C)	1035	810	18	302
1202°F (650°C)	895	680	20	262
* Annealed tensile properties are typical for Condition A of ASTM A276; annealed hardness is the specified maximum.
