H beam

Home > product > Profile Steel > H beam
line

ASTM A36 H Beam

Page Navigation
Product Usage Product Specification Chemical Composition Mechanical Behavior Factory Other types Customer Factory Inspection
High Quality
Product
Mature Technical
Team
Safe and
efficient logistics
Quote Online Contact Us

Product Usage

ASTM A36 h beam applications:

  • Construction support beams for columns, angles & channels.
  • Platforms.
  • Bridges.
  • Machinery bases.

Product Specification

Product

H beam

Thickness

Web thickness 5MM to 16MM ;Flange 7MM to 28MM (9.54KG/M to 243KG/M)

Flange Width

50MM to 300MM

Web Height

100MM to 900MM

Length

12M

Fabrication

Cutting,Hole punching,Welding, Galvanized, Paint

Surface

Carbon black, Mild steel

Offer Standards

ASTM A36, A572-GR50，JIS SS400，EN S235JR, S355JR, S355J2

Inspection

Mill test certificate along with cargos, and TPI test also acceptable

Chemical Composition

CSiMnPSCu
ASTM A36≤0.25≤0.40≤0.80-1.20≤0.04≤0.05≥0.20


Mechanical Behavior

Grade

Yield Strength（Mpa）

Tensile Strength（Mpa）

Elongation（%）

ASTM A36≥250400-550≥20


Other types

H Beam weight per square foot pvq H Beam
H Beam weight table q235b H Beam structural
H Beam welding q235 hot rolled H Beam
H Beam yield strength sa612 H Beam
H Beam for crude oil tanks sae 1008 H Beam
H Beam for pressure vessels sae 1025 H Beam
