Product Usage

H beam is mainly used for large buildings that big cutting ability, good cross section stability (such as factories, high-rise building, etc.), and Bridges, ships, lifting transportation machinery, equipment foundation, support, foundation pile, etc.

Product Specification

Grade	Q235B
Technique	Hot Rolled
Thickness	5mm - 36.5mm or requirement
Application	Steel building
Length	6-12m or requirement
Standard	ASTM
Flange Width	100-400mm
Flange Thickness	7-34mm
Web Width	100-900mm
Web Thickness	5-16mm
Model Number	Q235B, Q345B,A36,ST37.Q235,etc.
Tolerance	±1%
Processing Service	Bending, Welding, Decoiling, Punching, Cutting
Delivery Time	within 7 days
Place of origin	shandong,China
Product name	H-Beam
Technical	Hot Rolled Beam
Flange Thickness	7-34mm
Flange Width	100-400mm
Web Thickness	5-16mm
Web Width	100-900mm
Type	HW,HM,HN
Standard	JIS, JIS,ASTM,DIN,GB,etc.
MOQ	1 Tons

Chemical Composition

	C	Si	Mn	S	P	Cr	Ni	Cu
Q235B	≤0.2	≤0.3	0.3~0.7	≤0.045	≤0.045	Allowable residual content≤0.3	Allowable residual content≤0.3	Allowable residual content≤0.3

Mechanical Behavior

Grade	Yield Strength（Mpa）	Tensile Strength（Mpa）	Impact test Temperature: 20°C
Q235B	≤16mm：≥235 16—40：≥225 40—100：≥215 100—150：≥195 150—200：≥185	370—500	≥27

Grade

Yield Strength（Mpa）

Tensile Strength（Mpa）

Impact test

Temperature: 20°C

Q235B

≤16mm：≥235

16—40：≥225

40—100：≥215

100—150：≥195

150—200：≥185

370—500

≥27
