Product Usage

Q345 galvanized steel plate is often used in as welding structural part in manufacturing of ship, railway and vehicles, bridges, boiler, pressure vessel container, steel oil tank, etc.

Product Specifications

Item Name	Q345 Galvanized Steel Plate
Grade	SPCC,SGCC,DC01,DC03,DC04,A36,Q235,Q345,S355,SAE 1010,1020,1008,1045, etc
Standard	JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc
Thickness	0.25 - 3mm, 3-20mm
Width range	600mm - 1500mm
Length	6000-12000mm
Size	1000mm2000mm, 1219mm2438mm, 1219mm*3048mm, or as required
Finish	Oiled/non-oiled/galvanized/bright/black/annealed,etc.
Lead time	7 to 25 working days after the receipt of 30% deposit
Payment terms	30%TT for deposit, 70% balance before shipment or LC at sight
Packing	Wooden pallet or according to customer's request

Chemical Composition

Steel Standard	Steel Grade	Chemical Composition
Steel Standard	Steel Grade	C≤	Mn	Si≤	P≤	S≤	V	Nb	Ti	Al≥
Q345	A	0.20	1.00~1.60	0.55	0.045	0.045	0.02~0.15	0.015~0.060	0.20	-
	B	0.20	1.00~1.60	0.55	0.040	0.040	0.02~0.15	0.015~0.060	0.20	-
	C	0.20	1.00~1.60	0.55	0.035	0.035	0.02~0.15	0.015~0.060	0.20	0.015
	D	0.20	1.00~1.60	0.55	0.030	0.030	0.02~0.15	0.015~0.060	0.20	0.015
	E	0.20	1.00~1.60	0.55	0.025	0.025	0.02~0.15	0.015~0.060	0.20	0.015

Mechanical Behavior

Steel Standard	Steel Grade	Yield Strength Mpa	Tensile Stregth Map	Elongation %
Q345	A	345	470~630	21
	B	345	470~630	21
	C	345	470~630	22
	D	345	470~630	22
	E	345	470~630	22
