Product Usage

Q235 material is commonly rolled into wire rod or round steel, square steel, flat steel, angle steel, I beam, channel steel, other sections and steel plates. These products are widely used in construction and engineering welded structures, to make steel bars or build factory buildings, high voltage transmission towers, bridges, vehicles, boilers, containers, etc., and also used as a mechanical part with less demanding performance such as less stressed rods, connecting rods, screws, nuts, ferrules, brackets, and stands, etc.

Product Specifications

Item Name	Q235 Galvanized Steel Plate
Grade	SPCC,SGCC,DC01,DC03,DC04,A36,Q235,Q345,S355,SAE 1010,1020,1008,1045, etc
Standard	JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc
Thickness	0.25 - 3mm, 3-20mm
Width range	600mm - 1500mm
Length	6000-12000mm
Size	1000mm2000mm, 1219mm2438mm, 1219mm*3048mm, or as required
Finish	Oiled/non-oiled/galvanized/bright/black/annealed,etc.
Lead time	7 to 25 working days after the receipt of 30% deposit
Payment terms	30%TT for deposit, 70% balance before shipment or LC at sight
Packing	Wooden pallet or according to customer's request

Chemical Composition

Steel Grade	Quality Grade	C	Si	Mn	P	S	Deoxidation Method
Q235	Q235A	0.22	0.35	1.40	0.045	0.050	Rimmed / Killed
	Q235B	0.20	0.35	1.40	0.045	0.045	Rimmed / Killed
	Q235C	0.17	0.35	1.40	0.040	0.040	Killed
	Q235D	0.17	0.35	1.40	0.035	0.035	Exceptionally Killed

Mechanical Behavior

Yield Strength (MPa, ≥); Thickness or Dia. (d) mm							Tensile Strength (MPa)
Steel Grade	Quality	d≤16	16< d ≤40	40< d ≤100	100< d ≤150	150< d ≤200	d≤100
Q235	Q235A	235	225	215	195	185	370-500
	Q235B
	Q235C
	Q235D
