Slab crystallizer copper plates are used in continuous casting for producing wide steel slabs destined for plate mills, pipe manufacturing, and heavy plate applications. They handle high casting speeds while preventing breakouts through precise heat extraction. Steel industries rely on these plates for efficient slab formation in integrated mills and specialty steel plants.
Slab crystallizer copper plate specifications include widths of 900-2200 mm, thicknesses of 25-40 mm, and lengths around 800-1200 mm, often with funnel-shaped upper sections for thin slabs. Materials feature Cu-Ag or Cu-Cr-Zr alloys for thermal conductivity over 350 W/mK and strength. Custom tapers, chrome coatings, and cooling channels optimize performance for specific slab dimensions.
Slab crystallizer copper plates provide excellent heat transfer, enabling higher speeds, reduced cracks, and longer campaigns up to 10+ hours. Their durability cuts maintenance and boosts yield in demanding conditions. Ideal for steel producers in construction, energy, and automotive sectors needing consistent slab quality.
| Attribute | Parameter | Description |
|---|---|---|
| Product Name | Crystallizer Copper Plate for Slabs | Copper plates used in slab continuous casting crystallizers to solidify molten steel slabs. |
| Application | Slab continuous casting | Forms and supports thin solidified shell in slab moulds during casting. |
| Copper Alloy Grade | Cu99.5% + Ag 0.07–0.1% | Copper-silver alloy increases recrystallization temperature and wear resistance. |
| Thickness Range | 40–60 mm | Typical thickness needed to withstand mechanical and thermal loads. |
| Length Range | 180–1120 mm | Lengths designed to fit different continuous casting machine moulds. |
| Cooling Method | Water-cooled copper plate | Cooling directly forces heat transfer for slab solidification. |
| Surface Coating | Cr plating (single layered) | Chromium plate enhances wear resistance but may peel after long use. |
| Thermal Conductivity | High (copper alloy typical values) | Ensures rapid heat extraction to maintain billet shell formation. |
| Design Features | Funnel shape, parallel plate, H²-shape layouts | Adapted to slab casting size and to optimize molten steel flow and heat transfer. |
| Typical Slab Thickness | 40–135 mm | Suitable for thin to medium slab continuous casting processes. |
| Service Life | 200–500 heats (+ use after grinding) | Effective life extended by design and coating refinements. |
| Quality Standards | Customized per CCM and customer requirements | Includes dimensional tolerances, surface finish, and alloy composition. |
| Industries | Steel mills with slab casting machines | Applied in integrated steelmaking and rolling mill feedstock production. |
