Product Usage

A516 is the industry's most popular Pressure Vessel grade of steel plate. It is produced in grades 55, 60, 65, or 70. The most common is Grade 70, sometimes referred to as A516-70. A516 GR70 carbon steel applications include:Bridges,Buildings,Automotive and truck parts,Railroad cars,Cargo containers,Tote boxes,Construction equipment,Structural tubing,Lighting standards,Transmission poles,etc

Product Specification

Product Name	Carbon steel plate
Thickness	3-200mm or as required
Width	600mm-1250mm or as required
Length	2-12m or as requirement
Other Common Size	12192438: 12202440: 15003000: 15006000:2438-6096: 2438"9143Can becustomized cut or nrocessed according to customers' recuirementc
Standard	GB/T700 standard: Q235A, Q235B, Q235C, Q235D, Q235E EN10025 standard: S235JR,S235J0, S235J2 DIN17100 standard: St33, St37-2, Ust37-2, RSt37-2, St37-3 DIN17102 standard: StE255, WstE255, TstE255, EstE255 ASTM standard: A36/A36M A36A283/A283M A283 Grade A,A283 Grade BA283 Grade C, A283 Grade D A573/A573M A573 Grade 58, Grade 65, Grade 70
Grade	Shipbuilding steel plate mainly used in ship build.Grades are:A32 AH32 A36 AH36 DH36 D32 DH32 etc
	High strength steel plate mainly used in Bridges,power station eguipment. Grades are:Q460C/D/E, Q235B/C/D/E, Q345B/C/D/E, Q609C/D/E
	Alloy steel plate mainly sued in machinery, structure, tools, etc. Grades are:40Cr,50Mn,65Mn,15CrMo,35Crmo,42CrMo etd
	Pressured vessel steel plate mainly used for produce pressure vessel Grades:Q245R,Q345R,Q370R etd

Chemical Composition

CARBON MAX, ≤1/2" THICK	0.27%
CARBON MAX, >1/2" & ≤2" THICK	0.28%
CARBON MAX, >2" & ≤4" THICK	0.30%
CARBON MAX, >4" THICK	0.31%
MANGANESE	0.85-1.20%
PHOSPHORUS MAX	0.025%
SULFUR MAX	0.025%
SILICON	0.15-0.40%

Mechanical Behavior

GRADE	YIELD POINT (KSI)	TENSILE STRENGTH (KSI)	MIN. 8” ELONGATION %
A516	38	70-90	17
