Product Usage

A283 carbon steel plate is often used in Building Construction,Bridge,Architecture,Vehicles Components ,hipping,High pressure container,Boiler,Large Structure steel etc

Product Specification

Product Name	Carbon steel plate
Thickness	3-200mm or as required
Width	600mm-1250mm or as required
Length	2-12m or as requirement
Other Common Size	12192438: 12202440: 15003000: 15006000:2438-6096: 2438"9143Can becustomized cut or nrocessed according to customers' recuirementc
Standard	GB/T700 standard: Q235A, Q235B, Q235C, Q235D, Q235E EN10025 standard: S235JR,S235J0, S235J2 DIN17100 standard: St33, St37-2, Ust37-2, RSt37-2, St37-3 DIN17102 standard: StE255, WstE255, TstE255, EstE255 ASTM standard: A36/A36M A36A283/A283M A283 Grade A,A283 Grade BA283 Grade C, A283 Grade D A573/A573M A573 Grade 58, Grade 65, Grade 70
Grade	Shipbuilding steel plate mainly used in ship build.Grades are:A32 AH32 A36 AH36 DH36 D32 DH32 etc
	High strength steel plate mainly used in Bridges,power station eguipment. Grades are:Q460C/D/E, Q235B/C/D/E, Q345B/C/D/E, Q609C/D/E
	Alloy steel plate mainly sued in machinery, structure, tools, etc. Grades are:40Cr,50Mn,65Mn,15CrMo,35Crmo,42CrMo etd
	Pressured vessel steel plate mainly used for produce pressure vessel Grades:Q245R,Q345R,Q370R etd

Chemical Composition

CARBON MAX	0.24%
MANGANESE MAX	0.90%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON MAX, PLATES ≤ 1 1/2" THICK	0.40%
SILICON, PLATES OVER 1 1/2" THICK	0.15-0.40%
COPPER MIN	0.20%

Mechanical Behavior

GRADE	YIELD POINT (KSI)	TENSILE STRENGTH (KSI)	MIN. 8” ELONGATION %
A283	30	55-75	22
