Product Usage

A572 steel plate is typically used in various structural applications due to its ability to bear heavy weight while still being relatively light and machinable. Some of the most common infrastructure applications for A572 plate include bridge construction and building construction.

While most commonly used in the infrastructure sector, A572 plate is also widely used in other industries, including:

Energy, for use in constructing transmission towers
Construction, for use in producing construction equipment
Industrial manufacturing, for use in producing machinery and truck parts
Road plate applications

Product Specification

Product Name	Carbon Steel Sheet
Material	Q195、Q215、Q235、Q255、Q275，A36, SS400, Q235B,Q345B，Q345C，Q345D，Q345E，Q390，Q390B，Q390C，Q390D，Q390E，Q420，Q420B，Q420C，Q420D,Q420E,Q460,Q460D,Q500C,Q500D,Q500E,Q550C,Q550D,Q550E,Q620C,Q620D,Q620E,Q690A,Q690B,Q690C,Q690D,Q690E,Q690D,Q690C,Q890C,Q890D,16Mo3,16MnL,16MnR,16Mng,16MnDR etc
Standard	GB,AISI,ASTM,JIS,DIN,API
Thickness	0.1-100mm or as your request
Width	1000, 1219, 1500, 1800, 2000mm or as your request
Length	2000mm,2440mm(8feet),2500mm,3000mm,3048mm(10feet),5800mm, 6000mm or as your requirements
Treatment/Technique	Hot rolled, cold rolled
Surface	Pickled,Black,Polishing,Checkered,Embossed etc
Applications	Used for bridge and construction riveting, bolted and welded structure, as well as general purpose structural steel quality of carbon steel, steel plate and bar steel etc
Trade Terms	EXW, FOB, CFR, CIF
Delivery time	Shipped in 7-15 days after payment
Package	Standard sea-worthy package or as required
SEAWORTHY PACKING	20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM
	40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM
	40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM

Chemical Composition

GRADE 42
CARBON MAX	0.21%
MANGANESE MAX	1.35%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON TO 1 1/2" THICK, MAX	0.40%
SILICON OVER 1 1/2" THICK	0.15-0.40%

GRADE 50
CARBON MAX	0.23%
MANGANESE MAX	1.35%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON TO 1 1/2" THICK. MAX	0.40%
SILICON OVER 1 1/2" THICK	0.15-0.40%

GRADE 55
CARBON MAX	0.25%
MANGANESE MAX	1.35%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON TO 1 1/2" THICK, MAX	0.40%
SILICON OVER 1 1/2" THICK	0.15-0.40%

GRADE 60
CARBON MAX	0.26%
MANGANESE MAX	1.35%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON MAX	0.40%

GRADE 65 ≤1/2" THICK
CARBON MAX	0.26%
MANGANESE MAX	1.35%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON MAX	0.40%

GRADE 65 OVER 1/2" TO 1 1/4" THICK
CARBON MAX	0.23%
MANGANESE MAX	1.65%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON MAX	0.40%

Mechanical Behavior

GRADE	YIELD POINT (KSI)	TENSILE STRENGTH (KSI)	MIN. 8" ELONGATION %
42	42	60	20
50	50	65	18
55	55	70	17
60	60	75	16
65	65	80	15
