Q215 steel sheet is used in the manufacture of anchor bolts, plow, chimneys, roof panels, rivets, low-carbon steel wire, sheet, pipe, rod, hook, bracket, welded structure.
Product Name | Carbon Steel Plate |
Material | Q195、Q215、Q235、Q255、Q275 |
level | A，B，C，D |
Width | 50MM~2200MM, according to customer's requirement |
THICKNESS | 1.8MM~20MM, according to customer's requirement |
TECHNIQUE | Hot Rolled / Cold Rolled |
PACKING | According to customer demand |
MOQ | 1 Ton, more quantity price will be lower |
ORIGIN | China |
DELIVERY TIME | Usually within 7-20 days after receipt of advance payment |
| Chemical Composition % | |||||||
| Steel Grade | Steel Grade | C (≤) | Si (≤) | Mn (≤) | P (≤) | S (≤) | Deoxidation |
| Q215 | Q215A | 0.15 | 0.35 | 1.2 | 0.045 | 0.050 | Rimmed / Killed |
| Q215B | 0.15 | 0.35 | 1.2 | 0.045 | 0.045 | ||
| Steel Grade | Quality | Yield Strength (≥N/mm2) | Tensile Strength (N/mm2) | Elongation (≥%) | Impact Test (V notch) | ||||||||||
| Thickness or Dia. Ø mm | Thickness or Dia. Ø mm | Temp. ℃ | Absorbed Energy (Vertical, ≥J) | ||||||||||||
| Ø ≤16 | 16 < Ø ≤ 40 | 40 < Ø ≤ 60 | 60 < Ø ≤ 100 | 100 < Ø ≤ 150 | 150 < Ø ≤ 200 | Ø ≤40 | 40 < Ø ≤ 60 | 60 < Ø ≤ 100 | 100 < Ø ≤ 150 | 150 < Ø ≤ 200 | |||||
| Q215 | Q215A | 215 | 205 | 195 | 185 | 175 | 165 | 335 – 450 | 31 | 30 | 29 | 27 | 26 | – | – |
| Q215B | +20 | 27 | |||||||||||||
