Not only does Q235 possess toughness, weldability, and excellent plasticity, it retains strength while offering outstanding cold-bending performance. It is perfect for welded structures, including factory buildings, steel bars, towers, boilers, bridges, containers, vehicles, and more. Q235 can also be used as mechanical parts, such as stands, stressed rods, nuts, connecting rods, brackets, and other components. Q235 and varying grades of steel plates can be cut to specification.
Product Name | Carbon Steel Plate |
Standard | AiSi, ASTM, bs, DIN, GB, JIS |
Grade | Carbon steel |
Technique | Hot Rolled |
Surface Treatment | Coated |
Width | 50-3500mm |
Length | Requirement |
Tolerance | ±1% |
Material | Q235/Q235B/Q345/Q345B/Q195/St37/St42/St37-2/St35.4/St52.4/St35 |
Technology | Cold Rolled.hot Rolled |
Thickness | 0.5MM-300MM |
MOQ | 1 Ton |
Delivery term | FOB CFR CIF CNF |
| Steel Grade | Quality Grade | C % (≤) | Si % (≤) | Mn (≤) | P (≤) | S (≤) |
|---|---|---|---|---|---|---|
| Q235 | Q235A | 0.22 | 0.35 | 1.4 | 0.045 | 0.05 |
| Q235B | 0.2 | 0.35 | 1.4 | 0.045 | 0.045 | |
| Q235C | 0.17 | 0.35 | 1.4 | 0.04 | 0.04 | |
| Q235D | 0.17 | 0.35 | 1.4 | 0.035 | 0.035 | |
| Quality Grade: A<B<C<D | ||||||
| Grade | Yield Strength | Tensile Strength | Elongation % | |||
|---|---|---|---|---|---|---|
| Q235 Steel | 235 Mpa | 370-500 Mpa | 26 | |||
| Test Sample:16mm steel bar, (Mpa=N/mm2) | ||||||
