s355 carbon steel plate

We supply the highest quality steel

[email protected]

13370586666

Carbon Steel Plate

Home > product > Carbon Steel Products > Carbon Steel Plate

Page Navigation

Product Usage Product Specification Chemical Composition Mechanical Behavior Factory Other types Customer Factory Inspection

Quote Online

Product Usage

S355 carbon steel plate has high strength and toughness, and is easy to process and weld, so it is widely used in construction, manufacturing, transportation, chemical and other fields. Specifically, carbon steel coils can be used in the following areas:
1. Construction field: Carbon steel coils can be used as structural materials for bridges, tunnels, high-rise buildings, bus stations and other buildings.
2. Manufacturing field: Carbon steel coils can be used to manufacture various products, such as automobiles, electrical appliances, machinery, appliances, etc.
3. Transportation field: Carbon steel coils can be used to manufacture transportation equipment such as railway tracks and train bodies.
4. Other fields: carbon steel coils can also be used in aviation, energy, chemical and other fields, such as for the manufacture of aircraft parts, engine parts, power station equipment, oil pipelines, storage tanks, reactors, etc.

Product Specification

Material	Q235,Q255,Q275,SS400,A36,SM400A,St37-2,SA283Gr,S235JR,S235J0,S235J2
Thickness	0.2-500mm,etc
Width	1000-4000mm,etc
Length	2000mm, 2438mm, 3000mm, 3500,6000mm,12000mm,or rolled,etc etc
Standard	ASTM,AISI,JIS,GB, DIN,EN
Surface	Black painted,PE coated,Galvanized,color coated,
Surface	anti rust varnished,anti rust oiled,checkered,etc
Technique	Cold Rolled, Hot Rolled
Certification	ISO, SGS,BV
price terms	FOB,CRF,CIF,EXW all acceptable
Delivery Detail	inventory About 5-7; custom-made 25-30
Loading port	any port in China
Packing	standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Payment Terms	T/T, L/C at sight,West Union,D/P,D/A,Paypal
Container size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
	40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
	40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Processing Service	Bending, Welding, Decoiling, Cutting, Punching
MOQ	25 Tons

Chemical Composition

			S355 Chemical Composition % (≤)
Standard	Steel	Grade	C	Si	Mn	P	S	Cu	N	Method of deoxidation
EN 10025-2	S355	S355JR	0.24	0.55	1.60	0.035	0.035	0.55	0.012	Rimmed steel is not allowed
		S355J0 (S355JO)	0.20	0.55	1.60	0.030	0.030	0.55	0.012	Rimmed steel is not allowed
		S355J2	0.20	0.55	1.60	0.025	0.025	0.55	–	Fully killed
		S355K2	0.20	0.55	1.60	0.025	0.025	0.55	–	Fully killed

Mechanical Behavior

Yield Strength

		S355 Yield Strength (≥ N/mm2); Dia. (d) mm
Steel	Steel Grade (Steel Number)	d≤16	16< d ≤40	40< d ≤63	63< d ≤80	80< d ≤100	100< d ≤150	150< d ≤200	200< d ≤250
S355	S355JR (1.0045)	355	345	335	325	315	295	285	275
	S355J0 (1.0553)
	S355J2 (1.0577)
	S355K2 (1.0596)

Tensile Strength

		S355 Tensile Strength (≥ N/mm2)
Steel	Steel Grade	d<3	3 ≤ d ≤ 100	100 < d ≤ 250
S355	S355JR	510-680	470-630	450-600
	S355J0 (S355JO)
	S355J2
	S355K2

Elongation

		Elongation (≥%); Thickness (d) mm
Steel	Steel Grade	3≤d≤40	40< d ≤63	63< d ≤100	100< d ≤ 150	150< d ≤ 250
S355	S355JR	22	21	20	18	17
	S355J0 (S355JO)
	S355J2
	S355K2	20	19	18	18	17
