Product Usage

Not only does Q235 possess toughness, weldability, and excellent plasticity, it retains strength while offering outstanding cold-bending performance. It is perfect for welded structures, including factory buildings, steel bars, towers, boilers, bridges, containers, vehicles, and more. Q235 can also be used as mechanical parts, such as stands, stressed rods, nuts, connecting rods, brackets, and other components. Q235 and varying grades of steel plates can be cut to specification.

Product Specification

Product Name	Carbon Steel Pipe
OD	1”~24''
Wall Thickness	2~25mm,SCH10~XXS
Length	Less than 12m
Steel material	10#,20#,45#,Q345,A106-B,20Cr,15CrMo,St37,St42,ASTM 4140 etc.
Standard	BS, GB, AST,API,JIS,ASTM,DIN
Usage	Structure pipe; High and low pressure boiler tube; Liquid delivery; Seamless steel pipe for petroleum cracking ,Oil pipe,Gas pipe
Ends	Plain ends or threaded with socket and plastic caps or beveled ends
Surface	Bared or black painted, galvanized or with oiled or client option
Package	Bags, bundles, losses or client option
Inspection	With hydraulic testing, eddy current , Infrared test
Technique	Hot Rolled/ Cold Drawn/Cold Rolled
Testing	Chemical Component Analysis, Mechanical Properties, Exterior Size Inspection, hydraulic testing etc.
Others	1.Special design available according to requirement 2.Anti-corrosion and high-temperature resistant with black painting 3.All the production process are made under the ISO9001:2000 strictly

Chemical Composition

Steel Grade	Quality Grade	C % (≤)	Si % (≤)	Mn (≤)	P (≤)	S (≤)
Q235	Q235A	0.22	0.35	1.4	0.045	0.05
	Q235B	0.2	0.35	1.4	0.045	0.045
	Q235C	0.17	0.35	1.4	0.04	0.04
	Q235D	0.17	0.35	1.4	0.035	0.035
Quality Grade: A<B<C<D Note: Q235B carbon content C can be ≤0.22% by agreement.

Mechanical Properties

	Metric	US/Imperial
Tensile Strength, Ultimate	400 – 550 MPa	–
Tensile Strength, Yield	250 MPa	–
Elongation at Break	20 %	20 %
	23 %	23 %
Modulus of Elasticity	200 GPa	29000 ksi
Compressive Yield Strength	152 MPa	22000 psi
Bulk Modulus	160 GPa	23200 ksi
Poissons Ratio	0.26	0.26
Shear Modulus	79.3 GPa	11500 ksi
