Product Usage

Q235 carbon steel plate, with moderate carbon content, good overall performance, good matching of strength, plasticity and welding performance, the most widely used and often rolled into wire rod or round steel, square steel, flat steel, angle steel, I-beam, channel steel, Window frame steel and other steel materials, medium and thick steel plates. Extensive use in architectural and engineering structures. It is used to manufacture steel bars or build plant frames, high-voltage transmission towers, bridges, vehicles, boilers, containers, ships, etc., and is also widely used as mechanical parts with low performance requirements.

Product Specifications

Product Name	Carbon Steel Coils
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Material	Q195, Q215,Q235,Q345,ST37, A36,45# ,16Mn, SPHC,SGCC,CGCC
Thickness(mm)	Hot Rolled Thickness:2.75mm-100mmCold Rolled Thickness:0.2mm-3mm As Your Request
Width(mm)	45mm-2200mm, As Your Request
Technique	Hot rolled / cold rolled
Surface	Bare,Black,Oiled,Shot Blasted,Spray Paint,Coated,Galvanized,or as Your Request
Coil ID	508-610mm or as per your request
Coil Weight	3~5 Tons or as per your request
Application	Construction, machinery manufacturing, container manufacturing, shipbuilding, bridges, etc.
Packing	Standard Export packing(Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet)

Chemical Composition

	C	Si	Mn	S	p
Q235	0.12%%-0.2%	≤0.3%	0.3%-0.7%	≤0.045%	≤0.045%

Mechanical behavior

Grade	Elastic Modulus（E/Gpa）	Poisson's ratio（V）	Tensile intensity（Mpa）	Yield Strength（Mpa） Thickness or diameter less than or equal to 16mm	Material linear expansion coefficient α （1/°C）	Elongation（δ5/%）（a is steel thickness or diameter）
Q235	200~210	0.25~0.33	370-500	235	1.20E-05	≥26（a≤16mm） ≥25（a>16-40mm） ≥24（a>40-60mm） ≥23（a>60-100mm） ≥22（a>100-150mm） ≥21（a>150mm）

Grade

Elastic Modulus（E/Gpa）

Poisson's ratio（V）

Tensile intensity（Mpa）

Yield Strength（Mpa）

Thickness or diameter

less than or equal to 16mm

Material linear expansion

coefficient α

（1/°C）

Elongation（δ5/%）

（a is steel thickness or diameter）

Q235

200~210

0.25~0.33

370-500

235

1.20E-05

≥26（a≤16mm）

≥25（a>16-40mm）

≥24（a>40-60mm）

≥23（a>60-100mm）

≥22（a>100-150mm）

≥21（a>150mm）
