Product Usage

Alloy 420 is used for a variety of applications where good corrosion and outstanding hardness is necessary. It is not usually used at temperatures exceeding 800oF (427oC) due to quick hardening and loss of corrosion resistance. Examples of applications that use alloy 420 include:

Cuttery
Knife blades
Surgical instruments
Needle valves
Shear blades
Scissors
Hand tools

Product Specification

Product Name:	Stainless Steel Angle Bar
Standard:	AISI/ASTM/BS/DIN/GB/JIS
Material:	201, 202, 301, 302, 304, 304L, 310S, 316, 316L, 321, 430, 430A, 309S, 2205, 2507, 2520, 420,410, 440, 904L ect, Or Customized
Length :	1-12m / As customer's Request
Type:	Equal or Unequal
Technique:	Hot Rolled/ Cold Rolled
Processing Service :	Bending , Welding , Punching , Cutting
Suface Treatment:	Black Paint/ Oiled / Galvanized
Usage:	Widely used in Bridge construction, Construction work, Ship Building, Machiney engineering etc.
MOQ:	3 Tons
Supply Ability:	5000 tons / month
Price Terms:	EXW FOB CIF CFR
Payment Terms:	30%TT Advance + 70% Balance

Chemical Composition

	C	Mn	Si	P	S	Cr
420	0.15 max	1.00 max	1.00 max	0.04 max	0.03 max	min: 12.0 max: 14.0

Mechanical Behavior

Tempering Temperature (°C)	Tensile Strength (MPa)	Yield Strength 0.2% Proof (MPa)	Elongation (% in 50mm)	Hardness Brinell (HB)
Annealed *	655	345	25	241 max
399°F (204°C)	1600	1360	12	444
600°F (316°C)	1580	1365	14	444
800°F (427°C)	1620	1420	10	461
1000°F (538°C)	1305	1095	15	375
1099°F (593°C)	1035	810	18	302
1202°F (650°C)	895	680	20	262
* Annealed tensile properties are typical for Condition A of ASTM A276; annealed hardness is the specified maximum.
