Along with a few other 5000 series alloys, 5052 is corrosion resistant against seawater and salt spray. Its corrosion resistance means it can be used for large marine structures that are sensitive to failure, like the tanks of natural gas tankers. This is why you see 5052 aluminum on boats in general.
You’ll frequently see 5052 alloy in architectural facades.
You often see 5052 alloy aluminum in kitchen cabinets, appliances, fans and fan blades, home freezers, clock plates, fencing, and more.
5052 alloy aluminum has made its way into aircraft, bus, and truck manufacturing, road and name signs, fuel lines and tanks, streetlights, and other hallmarks of the transportation industry.
5052 aluminum is frequently used for general sheet metal work, heat exchangers, flooring panels, rivets and wires, chemical drums and other equipment, pressure vessels, treadplate, containers, and more.
Alloy No. | Thickness (mm) | Width (mm) | Length (mm) | Temper |
A1050,A1060, A1070,A1100 | 1.0-10 | 20-2300 | 20-8000 | H12,H22,H14,H16,H18, H24,H26,etc |
3A21,A3003,A3105,A3004 | 1.0-10 | 20-2300 | 20-8000 | H14,H18,H24,etc |
A5052 ,A5005,A5083,A5754 | 1.0-10 | 20-2300 | 20-8000 | H18,H24,H32,H34,H111,H112 ,etc |
A6061,A6082,A6063 | 1.0-10 | 20-2300 | 20-8000 | T4,T6,,etc |
A8011 | 1.0-10 | 20-2300 | 20-8000 | H12,H22,H14,H16,H18,H24,H26, etc |
Packing : Export wooden pallets. The bundle wegiht not exceed 2MT. Loading:by 1x20GP, 1X20GP can load about 18MT | ||||
Standards:ASTM-B209. EN573-1, GB/T3880.1-2006 | ||||
Quality of material: totally free from defects like white rust, oil patches, roll marks, edge damage, camber, dents, holes, break | ||||
Application : Mainly used insigns, billboards, building exterior decoration, bus body, high-rise buildings and factories wall | ||||
MOQ | 5 tons | |||
Payment term： | T/T,L/C | |||
Delivery Time | 15 days after 30% T/T payment or receiving L/C copy | |||
Kind attention : Specifications can be customized as the customer’s requirements. | ||||
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti |
| 5052 | 0.45 Si/Fe | 0.0 | 0.1 | 0.1 | 2.2/2.8 | 0.15/0.35 | 0.1 | 0.0 |
| Strength Psi | Elongation % |
| |||
| Alloy & Temper | Ultimate | Yield Set 0.2% | 1/16” | ½” | Brinell Hardness |
| 5052-0 | 28,000 | 13,000 | 25 | 30 | 47 |
| 5052-H32 | 33,000 | 28,000 | 12 | 18 | 60 |
| 5052-H34 | 38,000 | 31,000 | 10 | 14 | 68 |
| 5052-H36 | 40,000 | 35,000 | 8 | 10 | 73 |
| 5052-H38 | 42,000 | 37,000 | 7 | 8 | 77 |
