3005 aluminum plates are routinely used in humid environments such as air conditioners, refrigerators, and undercars. They are also commonly used in building materials and colored aluminum plates. The 3005 aluminum plate has good formability, weldability and corrosion resistance. Used for processing parts that require good formability, high corrosion resistance and good weldability, or work that requires these properties and requires higher strength than 1000 series alloys, such as kitchenware, food and chemical product processing and Storage devices, tanks and tanks for transporting liquid products, various pressure vessels and pipes processed with thin plates, general utensils, heat sinks, makeup boards, photocopier drums, and ship materials
Alloy No. | Thickness (mm) | Width (mm) | Length (mm) | Temper |
A1050,A1060, A1070,A1100 | 1.0-10 | 20-2300 | 20-8000 | H12,H22,H14,H16,H18, H24,H26,etc |
3A21,A3003,A3105,A3004 | 1.0-10 | 20-2300 | 20-8000 | H14,H18,H24,etc |
A5052 ,A5005,A5083,A5754 | 1.0-10 | 20-2300 | 20-8000 | H18,H24,H32,H34,H111,H112 ,etc |
A6061,A6082,A6063 | 1.0-10 | 20-2300 | 20-8000 | T4,T6,,etc |
A8011 | 1.0-10 | 20-2300 | 20-8000 | H12,H22,H14,H16,H18,H24,H26, etc |
Packing : Export wooden pallets. The bundle wegiht not exceed 2MT. Loading:by 1x20GP, 1X20GP can load about 18MT | ||||
Standards:ASTM-B209. EN573-1, GB/T3880.1-2006 | ||||
Quality of material: totally free from defects like white rust, oil patches, roll marks, edge damage, camber, dents, holes, break | ||||
Application : Mainly used insigns, billboards, building exterior decoration, bus body, high-rise buildings and factories wall | ||||
MOQ | 5 tons | |||
Payment term： | T/T,L/C | |||
Delivery Time | 15 days after 30% T/T payment or receiving L/C copy | |||
Kind attention : Specifications can be customized as the customer’s requirements. | ||||
| Chhemical Element | Content (%) |
|---|---|
| Aluminum, Al | 95.7 - 98.8 |
| Manganese, Mn | 1- 1.5 |
| Iron, Fe | ≤ 0.70 |
| Silicon, Si | ≤ 0.60 |
| Copper, Cu | ≤ 0.30 |
| Zinc, Zn | ≤ 0.25 |
| Magnesium, Mg | 0.20 - 0.60 |
| Chromium, Cr | ≤ 0.10 |
| Titanium, Ti | ≤ 0.10 |
| Other (each) | ≤ 0.050 |
| Other (total) | ≤ 0.15 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 180 MPa | 26100 psi |
| Yield strength | 165 MPa | 23900 psi |
| Elongation | 7% | 7% |
| Elastic modulus | 69 GPa | 10000 ksi |
| Shear strength | 110 MPa | 16000 psi |
| Hardness, Brinell (@load 500 kg; thickness 10.0 mm) | 49 | 49 |
